Code findable here
C elegans (Caenorhabditis elegans) is a nematode worm with 302 neurons. This small number of neurons makes it an ideal model organism to study brains. As such, it has been used for things like whole brain emulation, connectome research, etc. As a result, we have extremely good optogenetic control over these worms, and have quite a comprehensive ability to read and write to a large fraction of the worm’s neurons.
At the same time, we’ve been able to peer deeper into machine brains through having access to every neuron’s activations, being able to train models to help us get a better understanding of what happens in the machine. One such model is the sparse autoencoder, which I first encountered through Anthropic’s work on dictionary learning.
To start, we load in a dataset of 189 calcium traces of worm neurons under different stimuli (I still can’t believe there isn’t a 302 neuron C Elegans activation dataset! also finding the dataset was by far the hardest part here). We then define a 1x expansion factor SAE on the neurons such that
$$ a = ReLU(W_{enc} x + b_{enc}); x^* = W_{dec} a + b_{dec} $$
Then, train this with MSE + Sparsity loss. After training, we autointerpret the SAE to see if we can pull out any selectivity for stimulus.
And yes! Some SAE neurons are selective for stimuli:
Stimulus: 10mM CuSO4 (n_on=480, n_off=4499)
#01 unit 180 d=+0.334 on=6.562 off=5.358
#02 unit 20 d=+0.158 on=1.380 off=1.064
#03 unit 352 d=+0.080 on=0.572 off=0.471
#04 unit 214 d=+0.035 on=3.296 off=3.111
#05 unit 234 d=+0.000 on=0.000 off=0.000
Stimulus: Control (n_on=479, n_off=4500)
#01 unit 180 d=+0.612 on=7.348 off=5.274
#02 unit 331 d=+0.599 on=1.275 off=0.457
#03 unit 1 d=+0.570 on=3.326 off=1.147
#04 unit 366 d=+0.517 on=6.454 off=2.993
#05 unit 323 d=+0.410 on=1.244 off=0.591
#06 unit 359 d=+0.327 on=0.976 off=0.341
#07 unit 238 d=+0.090 on=0.053 off=0.037
where the unit corresponds to the hidden neuron.
